Part Number: TBN30406 / Vendor ID Number: 10831 / Custom:
KYOCERA Precision Tools TBN30406

KYOCERA Precision Tools TBN30406
by KYOCERA Precision Tools

Add To Quote
Add To Estimate
Add To Wishlist
Compare Item
Qty
Product Overview
Kyocera EZBR 060060003NB KBN05M Grade CBN, Micro Boring Bar
Kyocera EZBR 060060003NB KBN05M Grade, Right-Hand, Micro Bar with a 6.00mm Minimum Bore Diameter for (H) Hardened Materials Boring Applications
Product Availability
    Item is usually in stock, but we'll be in touch if there's a problem
Chipbreaker:
Material:
Primary Workpiece Material:
Additional options that would change other selections
Info & Guides
PDF
Technical Details
Details
Category:
Cutting Tools
Subcategory:
Boring
Subtype:
Indexable Cutting Tools
Category Level 4:
Micro Boring Bars
Coating Process:
PVD
Insert Holding Method:
Screw
Material:
CBN
Primary Workpiece Material:
(H) Hardened Materials
Additional Manufacturer Part Number:
8838506
ANSI Part Number:
EZBR060060003NBKBN05M
Application:
Micro Boring
California Prop 65 Item:
View
Country of Origin:
US, JAPAN, CHINA, SOUTH KOREA, OTHER
Discount Category Description:
CBN / PCD
ECCN:
EAR99
Feature 1:
Adjustable overhang length (EZ Adjust Structure)
Feature 2:
Minimized deviation of the cutting diameter
Feature 3:
Various EZ Bar sizes and styles for a wide range of small internal machining applications
Feature 4:
Without chipbreaker for non-ferrous machining applications
Feature 5:
Compatible with EZH060… style sleeves
Hand:
Right-Hand
Harmonized Code:
8209.00.0030
Insert Grade:
KBN05M
ISO Part Number:
EZBR060060-003NB
Material Group / Grade:
KBN05M
Min Order Qty:
1
Origin:
JPN
Pack Height:
0.630
Pack Length:
3.819
Pack Width:
1.024
Product URL:
https://app.catsy.com/app/share/739/o/collections/4004662142/digitalcatalog/item?sku=8838506
Series Description:
EZ Bar
Series.1:
EZB
Shipping Weight:
0.0300
Tool Style:
EZB-NB
Unit (inch/mm):
mm
UNSPSC:
23241601
UNSPSC Title:
Boring Tool
Video 1:
https://www.youtube.com/watch?v=JImahR4sSTw
[DCON] Connection Diameter (Decimal Inch):
0.2362
[DCON] Connection Diameter (mm):
6.00
[DMIN] Minimum Bore Diameter (Decimal Inch):
0.2362
[DMIN] Minimum Bore Diameter (mm):
6.00
[H] Shank Height (Decimal Inch):
0.2205
[H] Shank Height (mm):
5.60
[KAPR] Tool Entering Angle (Degree):
95
[LU] Usable Length (Decimal Inch):
1.1811
[LU] Usable Length (mm):
30.00
[RE] Corner Radius:
0.001"
[RE] Corner Radius (mm):
0.035
Manufactured By:
KYOCERA Precision Tools
